Specifications

Piezoelectric accelerometer ( type)

Measurement range

Acceleration：0.1～199.9m/ s² Peak(RMS×1.414)

Velocity： 0.1～199.9 mm/s RMS

Displacement： 0.001～1.999 mm P-P(RMS×2.828)

Measurement accuracy：80Hz

Acceleration: ±5% ±2 digits

Measurement frequency range

Acceleration：10Hz～1kHz(LO)

1kHz～15kHz(HI)

Velocity：10Hz～1kHz

Displacement ：10Hz～1kHz

The battery ：6F22(9V)×1

Power supply ： 9V 7mA

Battery life :  About 25h continuous use(at25℃with manganese battery).

Ambient conditions:-10 to +50℃ , 30 to 90%RH(no condensation).
